Pressure Hydrometer Cylinder Type : K26150 Brand : Koehler Instrument Co. Inc., USA.

  • Merk : Koehler Instrument Co. Inc.,
  • Minimal Pembelian : 1 Unit
  • Maksimal Pembelian : 100 Unit
  • Pengiriman : 3 Hari Setelah Pembayaran
  • Lokasi : DKI Jakarta - Jakarta Barat
  • Harga : Rp. 1 / Unit
  • Dilihat : 588 Kali
  • Pembaruan : 17-04-2024 19:29
Dapatkan Spesifikasi Harga Pressure Hydrometer Cylinder Type : K26150 Brand : Koehler Instrument Co. Inc., USA. Produk Terbaik dari BINTANG INSTRUMENT Jual Alat test Air/ Udara/ Makanan/Safety/ Laboratory

Produk Detail

Pressure Hydrometer Cylinder
Type : K26150
Brand : Koehler Instrument Co. Inc., USA
Specification :

Test Method
Density and relative density measurements of light hydrocarbons, including Liquified Petroleum Gas (LPG), are used for transportation, storage and regulatory purposes. The measurement is made by floating a thermohydrometer in a sample that has been introduced into a pressure cylinder.

Features and Benefits
• Conforms to ASTM D1657; NF M 41-008 and related specifications
• Built-in safety relief valve
K26150 Pressure Hydrometer Cylinder
Transparent plastic cylinder mounted between machined aluminum end plates and surrounded by stainless steel safety guard. Use together with ASTM 310H Thermohydrometer to determine density or relative density of LPG and light hydrocarbons. Equipped with inlet, outlet and vapor vent valves for admitting sample and purging cylinder. End plates have positive sealing buna-N O-rings and are joined by sturdy steel support rods. Top plate detaches easily without tools for insertion or removal of thermohydrometer. Safety relief valve prevents unsafe pressure build-up inside cylinder. Mounted on a finished steel base.

Specifications
Conforms to the specifications of: ASTM D1657; GPA 2140; IP 235; ISO 3993; NF M 41-008

Safety relief valve: 200psi (1.4MPa)

Dimensions dia.xh,in.(cm)
8.25x23.75 (21x60)
Net Weight: 5 lbs (2.3kg)
Ordering Information


Catalog
Number
Product Description
K26150
Pressure Hydrometer Cylinder


Accessories

Catalog
Number
Product Description
251-000-001
ASTM 101H Thermohydrometer
Nominal Relative Density Range: 0.500 to 0.650
Standard Temperature,°F: 60/60
Temperature Range, °F: 30 to 90
251-000-004
ASTM 310H Thermohydrometer
Density Range kg/m3: 500 - 650
Standard Temperature, °C: 15
Temperature Range, °C: 0 to 35
